Product Summary

The SJA1000 is a stand-alone controller for the Controller Area Network (CAN) used within automotive and general industrial environments. The SJA1000 is the successor of the PCA82C200 CAN controller (BasicCAN) from Philips Semiconductors. Additionally, a new mode of operation is implemented (PeliCAN) which supports the CAN 2.0B protocol specification with several new features.

Parametrics

SJA1000 absolute maximum ratings: (1)supply voltage: -0.5 +6.5 V; (2)input/output current on all pins except TX0 and TX1: ±4 mA; (3)sink current of TX0 and TX1 together: 30 mA; (4)source current of TX0 and TX1 together: -20 mA; (5)operating ambient temperature: -40 +125 ℃; (6)storage temperature: -65 +150 ℃; (7)total power dissipation: 1.0 W.

Features

SJA1000 features: (1)Pin compatibility to the PCA82C200 stand-alone CAN controller; (2)Electrical compatibility to the PCA82C200 stand-alone CAN controller; (3)PCA82C200 mode (BasicCAN mode is default); (4)Extended receive buffer (64-byte FIFO); (5)CAN 2.0B protocol compatibility (extended frame passive in PCA82C200 compatibility mode); (6)Supports 11-bit identifier as well as 29-bit identifier; (7)Bit rates up to 1 Mbits/s; (8)24 MHz clock frequency; (9)Interfaces to a variety of microprocessors; (10)Programmable CAN output driver configuration; (11)Extended ambient temperature range (-40 to +125 ℃).
