Product Summary

The CS4351CZZ is a complete stereo digital-to-analog system including digital interpolation, fifth-order multi-bit delta-sigma digital-to-analog conversion, digital de-emphasis, volume control, channel mixing, analog filtering, and on-chip 2 Vrms line level driver. The advantages of the CS4351CZZ include: ideal differential linearity, no distortion mechanisms due to resistor matching errors, no linearity drift over time and temperature, high tolerance to clock jitter, and a minimal set of external components. These features are of the CS4351CZZ ideal for cost-sensitive, 2-channel audio systems including DVD players, A/V receivers, set-top boxes, digital TVs and VCRs, mini-component systems, and mixing consoles.

Parametrics

CS4351CZZ absolute maximum ratings: (1)Input Current, Any Pin Except Supplies Iin: - ±10 mA; (2)Digital Input Voltage Digital Interface VIN-L: -0.3 VL+ 0.4 V; (3)Ambient Operating Temperature (power applied)TA: -55 125 °C; (4)Storage Temperature Tstg: -65 150 °C; (5)DC Power Supply High Voltage Analog power VA_H: -0.3_14V; (6)DC Power Supply Low Voltage Analog power VA: -0.3_3.63V; (7)DC Power SupplyDigital power VD: -0.3_3.63V; (8)DC Power SupplyInterface power VL: -0.3_3.63V.

Features

CS4351CZZ features: (1)Multi-bit Delta-Sigma Modulator; (2)24-Bit Conversion; (3)Up to 192 kHz Sample Rates; (4)112 dB Dynamic Range; (5)-100 dB THD+N; (6)+3.3 V, +9 to 12 V, and VL Power Supplies; (7)2 Vrms Output into 5 kΩ AC Load; (8)ATAPI Mixing; (9)Low Clock Jitter Sensitivity; (10)Popguard Technology® for Control of Clicks and Pops.
