Product Summary

The FR024N from International Rectifier utilize advanced processing techniques to achieve the lowest possible on-resistance per silicon area. This FR024N, combined with the fast switching speed and ruggedized FR024N design that HEXFET Power MOSFETs are well known for, provides the designer with an extremely efficient device for use in a wide variety of applications.

Parametrics

FR024N absolute maximum ratings: (1)Continuous Drain Current, VGS @ 10V, ID @ TC = 25℃: 17; (2)Continuous Drain Current, VGS @ 10V, ID @ TC = 100℃: 12 A; (3)Pulsed Drain Current, IDM: 68; (4)Power Dissipation, PD @TC = 25℃: 45 W; (5)Linear Derating Factor: 0.30 W/℃; (6)Gate-to-Source Voltage, VGS: ±20V; (7)Single Pulse Avalanche Energy, EAS: 71mJ; (8)Avalanche Current, IAR: 10A; (9)Repetitive Avalanche Energy, EAR: 4.5mJ; (10)Peak Diode Recovery dv/dt, dv/dt: 5.0V/ns.

Features

FR024N features: (1)Ultra Low On-Resistance; (2)Surface Mount; (3)Advanced Process Technology; (4)Fast Switching; (5)Fully Avalanche Rated.

Diagrams

FR024N simplified diagram

FR02FC10P
FR02FC10P
