Product Summary
The QSC1100 amplifier enables CDMA2000 handsets for emerging markets. In addition to supporting features such as downloadable polyphonic ringtones and color displays, the QSC1100 solution doubles talk time compared to currently available CDMA2000 handsets. The solution integration of baseband modem, RF transceiver, power management and system memory into a single chip reduces the number of discrete components required, reduces bill-of-materials costs and delivers board-area savings of more than 50%. The QSC1100 solution offers a wide range of features to deliver a superior user experience, including voice/SMS and support for downloadable polyphonic ringtones and wallpapers, 65 nm process technology and multiple-frequency operation, including 450 MHz, 800 MHz, 1900 MHz and 2100 MHz.
Parametrics
QSC1100 specifications: (1)output power (per channel): 50w at both channels driven: 8 ohms, 20-20 khz, 0.1% thd; 70w at both channels driven: 4 ohms, 20-20 khz, 0.1% thd; (2)output power (per channel): 140w at bridged-mono operation: 8 ohms, 20-20 khz, 0.1% thd; (3)dynamic headroom: 2 db at 8 ohms; 2.3db at 4 ohms; (4)distortion, thd @ 8 ohms: less than 0.1%, 0.01% typical at 20-20 khz, at rated power; less than 0.025% at smpte-im at rated power; (5)frequency response: 20-20 khz, +0, -1.0 db at 1 watt; (6)damping factor @ 8 ohms: greater than 200; (7)noise (a-weighted): 100 db below rated power; (8)voltage gain, db: 26; (9)sensitivity, v rms: 1.0; (10)input impedance: 10k unbalanced inverting; 20k balanced or unbalanced non inverting; (11)crosstalk: -70db, 20-20 khz; (12)controls: ac switch, circuit breaker, gain knobs, input programming dip switches, and bridging switch.
Features
QSC1100 features: (1)a pair of standard 1/4" headphone jacks on the front panel; (2)single piece aluminum extrusions; (3)integral rack mounting ears and heatsinks.
Diagrams
 |
