Product Summary

The L60852A is a general purpose Universal Serial Bus (USB) device controller. The L60852A provides a USB serial interface engine, USB transceiver, FIFOs, control/status registers, application interface circuit, and oscillation circuit thereby easily realizing a USB system. The L60852A supports four types of data transfer such as control transfer, bulk transfer, interrupt transfer and isochronous transfer, and also supports five or six endpoints.

Parametrics

L60852A absolute maximum ratings: (1)Power Supply, VCC, VSS = 0 V ,TJ = 25°C: –0.3 to + 4.6 v; (2)Input Voltage (Tolerant), VIT, VSS = 0 V ,TJ = 25°C: –0.3 to + 6.0 v; (3)Input Voltage (Normal), VI, VSS = 0 V ,TJ = 25°C: –0.3 to + VCC + 0.3 v; (4)Storage Temperature, TSTG: –65 to + 150 °C.

Features

L60852A features: (1)USB1.1 compliant; (2)Supports full-speed (12 Mbps); (3)Supports four types of transfer; control transfer, bulk transfer, interrupt transfer, and isochronous transfer; (4)Endpoints: 5 to 6 endpoints,Control EP: 1, Bulk/interrupt EP: 3, Isochronous/bulk/interrupt EP: 1 or 2; (5)Built-in FIFO for data storage; (6)A two-layer configuration of FIFO for each of EP1, EP2, EP4, and EP5; (7)8/16 bit DMA supported (EP1, EP2, EP4, and EP5); (8)Intelligent Serial Interface Engine (SIE); (9)Built-in USB transceiver circuit; (10)Ta = -20 to +80 °C; (11)VCC=3.0 to 3.6 V; (12)Interface with 5 V circuit is possible. (Input: 5 V tolerant, output: TTL); (13)Built-in 12 MHz /6 MHz oscillation circuit.

Diagrams

L60852A pin configuration
